Postion: Home>Product center

Name:Plastic Injection Molding Machine       Model:JZW7380
  • Product Parameters
  • About Products
  • Product Feature
  • Configuration Table
SPECIFICATION JZW7380
　A B C
INJECTION UNIT 　
Screw Diameter mm 90 95 105
Screw L/D Ratio L/D 23.2 22 19.9
Shot Size(Theoretical) cm3 2861 3188 3894
 Injection Weight(PS) g 2603 2901 3543
Injection Rate g/s 560 610 700
Plasticizing Capacity g/d 85 100 110
Injection Pressure Mpa 195 175 143
Screw Speed rpm 0~130
CLAMPING UNIT 　
Clamp Tonnage KN 7380
Toggle Stroke mm 950
Space Between Tie Bars mm 950×950
Max. Mold Height mm 960
Min. Mold Height mm 400
Ejector Stroke mm 280
Ejector  Tonnage KN 200
Ejector  Number  Piece 17
OTHERS 　
Max. Pump Pressure Mpa 16
Pump Motor Power KW 30+37
Heater Power KW 48.8
Machine Dimensions(L×W×H) m 10.1×2.6×2.8
Machine Weight t 38
Hopper Capacity L 100
Oil Tank Capacity L 1500
Platen Dimensions Face
Platen Dimensions Side
Machine Dimensions
